 Melting Furnace Spec. |
|
| Standard Frequency
(Hz) |
Form
DSIH-0000MF |
High Frequency generating power
(KW) |
Power input
|
| (V) |
(KVA) |
| 3000 |
DSIH-0030MF |
30 |
220 |
40 |
| DSIH-0050MF |
50 |
460 |
65 |
| DSIH-0075MF |
75 |
460 |
100 |
| DSIH-0125MF |
125 |
460 |
175 |
| 1000 |
DSIH-0150MF |
150 |
460 |
200 |
| DSIH-0175MF |
175 |
460 |
225 |
| DSIH-0200MF |
200 |
460 |
260 |
| DSIH-0225MF |
225 |
460 |
300 |
| DSIH-0250MF |
250 |
460 |
325 |
| DSIH-0300MF |
300 |
460 |
390 |
| DSIH-0350MF |
350 |
460 |
450 |
| DSIH-0400MF |
400 |
460 |
500 |
| DSIH-0500MF |
500 |
460 |
650 |
| 500
~ 180 |
DSIH-0650MF |
650 |
460 |
850 |
| DSIH-0750MF |
750 |
780 |
970 |
| DSIH-1000MF |
1000 |
780 |
1300 |
| DSIH-1200MF |
1200 |
780 |
1560 |
| DSIH-1500MF |
1500 |
1000 |
1950 |
| DSIH-2000MF |
2000 |
1000 |
2500 |
|
| |
| |
 |
| |
| Capacity of Inductor a Melting Furnace
|
|
| Quality of Material
KW
TEMP |
STEEL |
IRON |
COPPER |
ALUMINUM |
| 1650กษ |
1500กษ |
1150กษ |
750กษ |
| 30 |
30 |
35 |
50 |
30 |
| 50 |
55 |
60 |
100 |
55 |
| 75 |
90 |
120 |
150 |
90 |
| 125 |
180 |
200 |
340 |
180 |
| 150 |
220 |
250 |
430 |
230 |
| 175 |
265 |
295 |
510 |
275 |
| 200 |
315 |
345 |
615 |
320 |
| 225 |
360 |
410 |
710 |
370 |
| 250 |
410 |
460 |
810 |
410 |
| 300 |
525 |
590 |
1000 |
530 |
| 350 |
620 |
700 |
1200 |
630 |
| 400 |
725 |
810 |
1400 |
730 |
| 500 |
900 |
1000 |
1720 |
910 |
| 600 |
1050 |
1150 |
1950 |
1050 |
| 750 |
1350 |
1550 |
2500 |
1350 |
| 1000 |
1800 |
2000 |
3400 |
1800 |
| 1200 |
2200 |
2300 |
4050 |
2200 |
| 1500 |
2800 |
3100 |
5100 |
2800 |
| 2000 |
3700 |
4100 |
6700 |
3800 |
|
| |
